Straight Groove V-bits for Snapmaker (3 Bits)
Straight Groove V-bits for Snapmaker (3 Bits)
Straight Groove V-bits for Snapmaker (3 Bits)
Straight Groove V-bits for Snapmaker (3 Bits)
Straight Groove V-bits for Snapmaker (3 Bits)

Straight Groove V-bits for Snapmaker (3 Bits)

Regular price €16,99
/
Free shipping on orders over €99 and VAT included.

118 in stock

Order will be shipped in 1-3 business days after payment confirmation.
Tax-inclusive price & EU local warehouse delivery in 3-7 business days.

The straight groove v-bit is ideal for rotary projects and detailed oriented works. Its particular shape makes it stand out in most rotary carving tasks and could be customized through Snapmaker Luban (4-axis CNC functionality) to achieve optimal carving results.

Overall features:

• UF20 tungsten steel alloy with high hardness and wear resistance
• Longer shank and wider flute for more efficient carving on cylinders

* This bit is compatible with Snapmaker 2.0 and Snapmaker Artisan devices and can be used in both 4-axis CNC and regular CNC.

Compatibility:

• Snapmaker Artisan
• Snapmaker 2.0



Snapmaker 2.0
Straight Groove V-bits (3 Bits)

Snapmaker 2.0
Straight Groove V-bits (3 Bits)

Wear resistant

Broad application

Wider flute

Wear resistant

Broad application

Wider flute

Description

Straight Groove V-bits

UF20 tungsten steel alloy with high hardness and wear resistance, not only is it suitable for epoxy tooling material, but it is also compatible with a dozen materials including carbon fibersheet, MDF and ebony.

A better choice for 4-axis CNC

The longer shank and wider flute carve cylinders or similarly shaped objects more efficiently.

High Precision

Adjust settings in Snapmaker Luban software and obtain optimal results with a few small tweaks.

Straight Groove V-bits
UF20 tungsten steel alloy with high hardness and wear resistance, not only is it suitable for epoxy tooling material, but it is also compatible with a dozen materials including carbon fibersheet, MDF and ebony.
A better choice for 4-axis CNC
The longer shank and wider flute carve cylinders or similarly shaped objects more efficiently.
High Precision
Adjust settings in Snapmaker Luban software and obtain optimal results with a few small tweaks.

Showcases

Hollow Candle Holder

Device:

Snapmaker 2.0 A350 and Rotary Module A350

Time:

9 h

Processing Mode:

4-axis CNC carving

Material:

Epoxy tooling material

Work Speed:

400 mm/min

Step Down:

5 mm

Lion With A Shield

Device:

Snapmaker 2.0 A350 and Rotary Module A350

Time:

9 h

Processing Mode:

4-axis CNC carving

Material:

Epoxy tooling material

Work Speed:

400 mm/min

Step Down:

5 mm

Astronaut

Device:

Snapmaker 2.0 A350 and Rotary Module A350

Time:

10 h

Processing Mode:

4-axis CNC carving

Material:

Epoxy tooling material

Work Speed:

400 mm/min

Step Down:

5 mm

Astronaut

Device:

Snapmaker 2.0 A350 and Rotary Module A350

Time:

10 h

Processing Mode:

4-axis CNC carving

Material:

Epoxy tooling material

Work Speed:

400 mm/min

Step Down:

5 mm

Specifications

Shank Diameter Included Angle Total Length Flute Length Tip Diameter

3.175 mm

20°

50 mm

24 mm

0.3 mm

Shank Diameter:

3.175 mm

Included Angle:

20°

Total Length:

50 mm

Flute Length:

24 mm

Tip Diameter:

0.3 mm



Notes:
• This bit is compatible with Snapmaker 2.0 devices and can be used in both 4-axis CNC and regular CNC.
• Due to the longer shank, please pay attention to the work speed and step down settings to avoid potential risks of bit breaking and danger.

Customer Reviews

Based on 9 reviews
67%
(6)
33%
(3)
0%
(0)
0%
(0)
0%
(0)
G
George Brintzenhoff
Good

The quality of the metal used to make these bits is great.

W
William Fritsche
Straight Groove V bit 3 pack

I would like to get a pack of 100 or at least 25 at a time.
I have order these all the time look at my account Snapmaker and you will see.

Best Regards,
Will,
William Fritsche
CEO Wills Printing Creations
US Navy Veteran
Jacksonville, FL
Email --- [****]
Web Site --- www.willsprintingcreations.com
[****]

K
Kurt Weber

Straight Groove V-bits for Snapmaker 2.0 (3 Bits)

S
Suoltan Alshuwaiey
wonderful bit

It is really fantastic bit

w
wentsung Peng
Small problems with using Straight Groove V-bit

I used the Straight Groove V-bit to complete the Rotary Module CNC Carving a few days ago, and everything was almost perfect. My material is wood with a diameter of 50cm. When the Straight Groove V-bit goes deep into the center of the wood, because the radius of the wood exceeds the length of the flute, the wood touches the shaft and generates a lot of friction and noise, causing the 3-jaw Chuck to loosen. The diameter of 3-jaw Chuck Inward-clamping of Rotary Module can reach 60CM. The above problem may be more obvious. Is there a solution?
